SYS-368

Model

SYS-368

Panel Thickness

10-60mm

Edge Band Thickness

0.3-3mm

Panel Width

≥60mm

Panel Length

≥150mm

Feeding Speed

15-23m/min

Working Pressure

0.6Mpa

Voltage

380V/50HZ/3PH

Gluing Motor

0.75KW       50HZ    1400RPM

End Cutting Motor

0.37KW * 2    200HZ  12000RPM

Fine Trimming Motor

0.75KW * 4    300HZ  18000RPM

Buffing Motor

0.37KW * 2    50HZ    1400RPM

Conveyor Motor

2.2KW

Glue Pot Heating Power

2.4KW

Assistant Heating Power

0.3KW

Lighting Power

0.05KW

Lifting Motor

0.25KW

Total Power

10.43KW

Dimension

4700x1000x1650mm

Wooden Crate Package

4800×1050×1760mm
