Cast Iron Table Dimension

980*560*70mm

length extension table

760*630*50mm

width cutting extension table

575*550*50mm

 Main Saw Diameter

300mm

Main Saw Blade Diameter Maximum

315mm

Main Saw Bore Diameter

30mm

Max. Cutting Height With Bade at 90

80mm(φ300)

Max. Cutting Height With Bade at 45

50mm(φ300)

Main Motor Power

4.0/5.5KW

Main Blade Speed

4000/6000RPM

Scorning Saw Blade Diameter

120mm

Scorning Saw Bore Diameter

20mm

Scorning Saw Motor Power

0.75/1.1KW

Scorning Blade Speed

8000RPM

Max. Cutting Width

1250mm

Max. Cutting Length

3700mm

Blade Tilting Adjustment

0-45°

Main Saw Height Adjustment

Manual

Scorning Saw Height Adjustment

Manual

Dust Guard Outlet Diameter

80mm

Dust System Outlet Diameter

100mm

Dimension of Wood Packing Carton

2100*1100*1100mm(Main Crate)

3950*420*270mm (Sliding Table )

Dimension

3850*3150*900mm

G. W.

800KG
